Can produce parts quickly and efficiently, reducing production time and increasing productivity.
Max tapping diameter : M6/M12 mm
Max drilling diameter : ￠8/￠12 mm
| Main axis Diameter | 27mm | |
| Maximum machining diameter | 26mm | |
| Feeding length at one time | 105mm | |
| Maximum working speed | 8000rpm | |
| Spindle | Number of tools | 5 pcs
|
| Tool specifications | 12x12mm | |
| Front side of spindle tool NO(pcs) | 4×φ20 round hole (ER11) | |
| Maximum tapping diameter (front) | M6/M12 mm | |
| Maximum drilling diameter (front) | ￠8/￠12 mm | |
| Number of spindle radial power tools | M6/M12 | |
| Maximum drilling diameter (radial)
Standard (52:30)/Optional (32:30) |
ER11x2 + ER16x2 | |
| Maximum tapping diameter (radial
Standard (52:30)/Optional (32:30) |
￠6/￠8 | |
| Maximum saw blade milling cutter diameter (side mounted)
Guide bushing mode/no guide bushing mode |
M6/M8 | |
| Guide bushing mode/no guide bushing mode | ￠30/￠35 | |
| Other parameters | Main shaft/auxiliary shaft motor | 3.7 kw |
| Radial power tool motor | Yaskawa:0.75/SYNTEC ：:1 kw | |
| Servo motor (X1, Z1, Y) | Yaskawa:0.75/SYNTEC ：:1 kw | |
| Lubrication pump motor | 0.1 kw | |
| Cooling pump motor | 0.35 kw | |
| Rapid feed speed (factory setting) m/min | X/Y/Z: 24/24/28 m/min | |
| Cooling box capacity | 130 L | |
| Lubrication device capacity | 3 L | |
| Center height | 1050 mm | |
| “Outline dimensions (length × width × height) | 1850×1080×1800 mm | |
| Machine weight | 1800 kg | |
| Machine power (kw) | Yaskawa:7.5/SYNTEC:8.5 kw | |
The machine tool bed is integrally cast with resin sand, with strong seismic resistance and lessdeformation, so as to ensure the high rigidity and high precision of the machine tool.
Widely used in electronic, communication, medical, household appliances and other industry parts.
Japan Ankawa motor drive, Japan NSK bearing, Taiwan silver,silver Thailand rod guide,Taiwan Baoyuan new generation system.
| Name | Name |
| CNC System(standard is Taiwan SYNTEC system with 10.4inch color LCD display. Taiwan LNC, Fanuc, Mitsubishi as an option) | Product Conveyor Unit |
| Spindle clamping device | Oil Mist Separator |
| Second spindle clamping device | Air compressor |
| Synchronous Rotary Guide Bushing | Working lamp |
| Parts Adapter | Warning Light |
| Synchronization device | RS-232 interface and DNC function |
| Automatic lubrication system | Rear power unit |
| Cutting oil system | Sub-spindle blowing device |
| Air cooling temperature control system | leakage protection device |
